Support for professionals
Find quick answers to common questions about our products, services, and support. Easily access the information you need to enhance your experience and resolve your queries efficiently.
- General questions
- Using hearing instruments
- Software issues
- Remote Adjust
- Error messages
General questions
The following section provides programming information for each shell type, programming cable information and iCube II programming information.
ITEs
Battery: Must be removed when programming using a cable. Insert battery into battery door when programming using iCube II.
Battery door: Must be removed to insert cable. Must be closed with battery in place when using iCube II.
On/Off Switch: There is no physical on/off switch on the hearing aid. The hearing aid will power on when the programming cable is connected to the hearing aid or when the battery door is closed with battery in place when using iCube II.
10A cable: 10A programming cable (white). Insert right or left programming cable for the appropriate side. Note: using the black 10A programming cable is not recommended as it may damage the battery contacts.
312 and 13 cables: DIN/Battery Cable Style 5. Insert right or left programming cable for the appropriate shell style and battery size.
All wireless ITEs will use NOAHLink Wireless.
BTE and Moxi family (RIC)
Battery: Must be removed when programming using a cable. Insert battery into battery door when programming using iCube II or NOAHlink Wireless.
Battery door: Must be opened to insert cable. Must be closed with battery in place when using iCube II or NOAHlink Wireless.
On/Off Switch: There is no physical on/off switch on the hearing aid. The hearing aid will power on when the programming cable is connected to hearing aid or when the battery door is closed with battery in place when using iCube II or NOAHlink Wireless.
Cable: DIN/CS44 Plug Cable Style 4.
(Note: Hearing instrument controls, accessories, Easy-t, audio streaming and automatic microphone options are deactivated during programming.)
Programming cable information
The programming cable for each shell style and battery size is listed in the table below.
IIC and ITEs
HI-PRO cables 2m:
Right, Red | 10A | 058-0099 | (white) |
Right, Red | 312 | 058-5008 | (521-383-008) |
Right, Red | 13 | 058-5010 | (521-384-008) |
Left, Blue | 10A | 058-0098 | (white) |
Left, Blue | 312 | 058-5007 | (521-383-007) |
Left, Blue | 13 | 058-5009 | (521-384-007) |
NOAHlink cables 0.5 m:
Right, Red | 10A | 058-1070 | (white) |
Right, Red | 312 | 058-5122 |
|
Right, Red | 13 | 058-5124 |
|
Left, Blue | 10A | 058-1071 | (white) |
Left, Blue | 312 | 058-5123 |
|
Left, Blue | 13 | 058-5125 |
|
BTEs and Moxi family
HI-PRO cables 2m: DIN/CS44 Plug Cable Style 4
Right, Red | 058-5006 | (521-381-008) |
Left, Blue | 058-5005 | (521-381-007) |
Generic Black | 058-5078 |
|
NOAHlink cables 0.5 m:
Generic Black | 058-5059 |
Programming with iCube II information
iCube II is available for wireless cable free programming.
To add an iCube II for wireless programming capability:
Ensure that the Bluetooth® icon in the computer system toolbar looks blue. If the icon is red:
- If using an external Bluetooth device, ensure it is plugged in
- If using an internal Bluetooth device, ensure it is turned on
- Check your computer owner’s manual regarding enabling the Bluetooth device
Ensure iCube II is powered on and the battery is charged.
Ensure iCube II is positioned within ~ 10 meters of the programming computer.
If using iCube II via USB connection, check the USB cable and ensure it is firmly plugged into the computer and iCube II.
- Click on ‘Options’ on the top menu bar and select ‘iCube II Configuration’
- Ensure the check box ‘Enable iCube II for fitting’ is selected
- Click on the ‘Add iCube II...’ button. Follow the on-screen instructions in the iCube II Pairing Assistant.
After adding iCube II, you can use this interface for programming your wireless hearing instruments. iCube II must be charged and enabled in the software prior to programming wireless instruments. For further details regarding iCube II function, please refer to the Complete guide to iCube II. General steps for programming with iCube II are listed below:
- Insert appropriate battery into the hearing instruments and close the battery doors
- Place hearing instruments inside iCube II neckloop/antenna or place hearing instruments in your client's ears and position iCube II neckloop around client's neck
- Select iCube II as the desired programming interface from the dropdown list on the Instruments>Selection screen
- Click on the Detect button. A detection dialog box will appear
- New wireless BTE or RIC fittings will need to be designated as right or left instruments using the assignment buttons on the detection dialog box
- Custom ITE fittings will have already been designated as right or left hearing instruments during the production process.
Programming with NOAHlink Wireless
Install Unitron TrueFit before connecting NOAHlink Wireless with computer. The NOAHlink Wireless driver is installed during installation of Unitron TrueFit.
After successful Unitron TrueFit installation attach NOAHlink Wireless to any USB port on the PC using the supplied USB cable. A 2-3 second solid green light indication will confirm that NOAHlink Wireless is powered.
- Place NOAHlink Wireless on the table with a clear line-of-sight to the hearing instruments, which should be within a range of 10 feet (3 metres)
- Avoid placing the NOAHlink Wireless in a USB hub with other USB devices (e.g. Bluetooth dongle), as this can decrease the efficiency of the NOAHlink Wireless
- When fitting hearing instruments inside a sound booth place the NOAHlink Wireless inside or close to the booth
- It is recommended not to use USB cables between the NOAHlink Wireless and the PC exceeding a length of 10 feet (3 metres).
Insert batteries into the hearing instruments and close battery doors.
Select NOAHlink Wireless to be the fitting device.
Click the Detect button.
Identify hearing instruments by either pressing the push button of the hearing instrument (if applicable) to see a highlight in dialog or click the Play Beep button to play a beep in the corresponding hearing instrument.
Assign side information to the hearing instruments.
Click Continue and follow the workflow.
Yes, equalizer adjustments can be viewed in the App Equalizer tool box on the Fitting->Tuning screen. Adjustments to the automatic program apply to all environments and are not adjusted individually for each environment.
To choose the desired language for the Getting Started Guide, click on File > Print and select the Getting Started Guide language from the provided options, then proceed to print the appropriate Getting Started Guide(s) or from the End Fitting > Fitting Summary screen, select a language at the bottom of the screen, check off which Getting Started Guides you would like to print and click Print.
To change the technology level of a FLEX:TRIAL device, go to the Instruments > Technology Change screen, click on the new technology level that you would like to use and follow the instructions in the wizard. You may be prompted to change the technology level of a FLEX:TRIAL device from the Detection dialog box. If you choose to change the technology level, then follow the steps in the wizard to do so.
Navigate to the End Fitting>HI Setup screen, and in the TV Connector task box select “Manual” (not available in pre-Discover hearing instruments).
Upon detecting devices, TrueFit will read the latest values for the equalizer. The Tool Box preview will indicate if your client has made any changes in the current program you are reviewing. If changes have been made you can see them in the App Equalizer tool box on the Fitting->Tuning screen. If your client has not make any changes to the selected program, the values will be set to zero. Note: App equalizer changes made to streamed signals, including Media, Bluetooth Phone and Roger Direct cannot be displayed in TrueFit.
Click on the label under each slider to highlight the region in the curve displays: Bass, Mid and Treble.
The pediatric fitting mode settings can be accessed from the Fitting Mode icon at the top right of all screens in Unitron TrueFit. Clicking on the icon will show the standard and pediatric fitting mode options. When you select one of these options, you will be given the chance to accept the change in fitting mode or cancel. Also, when you start a new session for a pediatric client, you will be provided with the opportunity to select a pediatric fitting mode right away via the generated dialog box.
To set up password protection, go to Options > Preferences > Fitting Session > Fitting, check the box beside Enable password-protected fittings, and enter the password you wish to use. Every time you save a fitting to hearing instruments with this option selected, the fitting information cannot be read back from the hearing instrument unless the correct password is in the software. Passwords are case sensitive and you have unlimited tries (in case you have deleted the password from your computer and need to input the same one again).
- Ensure iCube II is powered on and the battery is charged
- Enable iCube II in Options > iCube II Configuration
- Use the iCube II dedicated dongle
- Ensure iCube II is positioned within ~ 10 meters of the programming computer
- Run an iCube II check which can be found in the Options > iCube II Configuration menu. If the iCube II check cannot locate the iCube II, try deleting the iCube II from Unitron TrueFit and adding it back again using the Add iCube II button.
To transfer a fitting into FLEX:TRIAL devices, simply open the existing fitting session, connect the FLEX:TRIAL devices to the programming interface of your choice and click Detect. In the Detection dialog box, you may be prompted to change the technology level of the devices and you will be given the option to use the fitting from the current open session or from the newly detected hearing instrument. Select the option to use the fitting from the current open session (i.e., the client's own device settings) and then save to the FLEX:TRIAL devices.
These markers indicate the original position when the hearing instruments were detected. This provides a visual reminder of your client’s initial settings when you move the sliders or press reset.
Pressing the Reset button will return all of the sliders to the default (zero) position for the currently selected program, the curves will reflect the changes made and the App Equalizer settings for that program will be reset on the HIs.
If available in the product, the tinnitus masker is activated on the Fitting > Tuning screen in the Tinnitus Masker task box. Here you can select which device has the tinnitus masker enabled for the currently selected program. After activating the feature, you can also indicate whether or not the client control on the hearing instrument or remote control will adjust the masker level while in the currently selected program. The prescribed noise level can also be manipulated in the software via the provided controls.
The default settings for each of the available fitting modes can be modified in Options > Preferences > Fitting Session > Fitting Mode. The current defaults are provided in the table which can be expanded and modified as desired by clicking on the desired item and modifying it via the provided dropdown boxes.
Various phase canceller strengths are offered under Fitting > Configure Features > Phase Canceller to provide clinicians with the ability to address various degrees of feedback and any possible sound quality concerns. The default setting is 'Moderate' for the Automatic Program and all acoustic manual programs once the feedback optimization test has been performed as this strength has been found to provide the optimal feedback management performance. In those instances where a client reports concerns with the sound quality of tonal signals (e.g., music) or particular environmental sounds, clinicians could adjust the strength of the phase canceller downwards one step at a time to optimize the balance between lack of feedback and lack of sound quality complaints.
Using hearing instruments
Yes. You can configure the push button to function as a volume control if that option is available on the End Fitting > HI Setup screen. On this screen you will find a configuration dropdown box for the push button that allows you to choose the options such as Volume: Right up, Left down. Some options will enable DuoLink and will allow the client to push the button on one hearing instrument to adjust both hearing instruments.
When you use NOAHlink or HI-PRO, batteries should be removed from the hearing instruments. The required power is provided by the programming device in these situations. If you are using a wireless programming device, you need to insert batteries in the hearing instruments or ensure the hearing aids are charged for 3 hours prior to programming.
The volume control range is configured on the End Fitting > HI Setup screen in the Volume Settings task box. Here you can select the Volume Control Up option (off, 6 dB, 10 dB) and the Volume Control Down option (off, 6 dB, 10 dB, 20 dB) which determine the actual volume control range.
On the End Fitting > Beeps screen in the Trial Duration task box the left and right drop boxes indicate an approximate duration.
The feedback optimization test determines the maximum stable gain that can be provided in an individual fitting to ensure a feedback-free fitting. If the feedback test did limit the available gain beyond what is desired for the fitting, improvements to the feedback path can be made and the test can be re-run afterwards. Such improvements could involve reducing the amount of venting, improving the fit/retention of the ear mold, providing a more occluding dome for slim tube and RIC fittings. Whenever the acoustic coupling in a fitting is changed, the fitter should first navigate to the Instruments > Acoustics screen to properly include the acoustic change in the software logic, and then re-run the feedback optimization test in the Fitting > Feedback Optimization screen. If available, you may also select the checkbox to increase the gain by up to 5 dB.
The volume control can be disabled on the End Fitting > HI Setup screen using the Volume Settings box. Here you can set the Volume Control Up option to off, and the Volume Control Down option to off. Alternatively, you can ensure that the dropdown boxes associated with the hearing instrument controls in the End Fitting > HI Setup screen have been configured to not include a volume control (e.g., set the lever / dial to off via the provided dropdown box).
The program toggle and volume control functionality as well as other client controls are disabled during programming. Ensure that the hearing instruments have been re-started after programming by opening and closing the battery door. This will ensure that all the client controls, including the program toggle and volume control are enabled. Alternatively, it may be that the default loudness level and frequency of the beeps is not ideal for the client’s hearing loss or that the beeps have been disabled. To address this concern, navigate to the End Fitting > Beeps screen. In the Beep Setup task box adjust the beep intensity and frequency level via the provided dropdown boxes to improve audibility of the indicators. In the Beep Enabling task box, it is possible to activate/deactivate the desired indicator beeps.
The amount of high frequency gain in the hearing instruments can be determined by a number of factors. Clinicians desiring more high frequency gain should ensure that the devices have been calculated to the desired target level using the Recalculate icon on the tool bar. The acoustics of the fitted hearing instrument(s) should also be configured in the software via the Instruments > Acoustics screen so that the calculation logic is appropriate. Also, should more gain be required, clinicians could navigate to the Fitting > Tuning screen and increase the Adaptation Manager setting in the Adaptation Manager box.
In addition, the reduction of available gain can occur following the feedback optimization test, i.e. it can hinder the amount of available high frequency gain for a particular fitting. Clinicians should view the feedback optimization screen to determine whether the currently used coupling and acoustic characteristics of the fitting have resulted in a restricted maximum stable gain curve after the feedback test. If necessary, changing to a more occluded fitting could provide the ability to offer more high frequency gain.
Software issues
- Ensure the correct programming cables or programming interface is being used (i.e. NOAHlink Wireless)
- Ensure that the programming cable is plugged firmly into the hearing instrument and into the programming interface
- Ensure the hearing instruments are sufficiently charged or place a fresh battery in the hearing instrument and listen to the unit to see if it is operating at all
If you have tried all of the above and are still unable to fix the problem, please contact Unitron for support.
- Unitron TrueFit supports the following Windows operating systems: Windows 10 and Windows 11. Unitron TrueFit does not support Macintosh operating systems.
- You must have administrator level rights to install Unitron TrueFit software. Installing Unitron TrueFit without administrator rights will cause the installation to fail
If there are any other errors during installation, it is best to contact Unitron for support.
- Select a different Noah client record. The client record could be damaged and this will cause Unitron TrueFit to fail
- Uninstalling and reinstalling may fix this issue. Uninstall Unitron TrueFit using the Windows Start > Settings > Control Panel > Add or Remove Programs or Start > Control Panel > Uninstall a program option. When the uninstall is complete, Unitron TrueFit can then be reinstalled using the installation CDs.
- Select a different NOAH client record. The client record could be damaged and this will cause Unitron TrueFit to fail
- Uninstalling and reinstalling may fix this issue. Uninstall Unitron TrueFit using the Windows Start > Settings > Control Panel > Add or Remove Programs or Start > Control Panel > Uninstall a program option. When the uninstall is complete, Unitron TrueFit can then be reinstalled using the installation CDs.
If you have tried all of the above and are still presented with an exception report window, please click on the Help > Support > Generate Support Package menu option and email the resulting zip file to Unitron for support. A screen shot of the error is often very helpful in solving the issue. To capture a screen shot, click the PrtScn button on your keyboard, paste the image into Windows Paint then save the file and include it with your email.
Select the Options > Preferences menu item. In the Preferences window select Presentation. Change the visual effects to either "Minimal visual effects" or "No visual effects".
- Open Unitron TrueFit by running it in Standalone mode. This can be done by double clicking on C:\Program Files (x86)\Unitron TrueFit\TrueFit.exe
- Now click on the menu item Help > Support > Unregister from Noah. Next click on the menu item Help > Support > Register with Noah; Unitron TrueFit should now be registered correctly.
- Open Unitron TrueFit by running it in Standalone mode. This can be done by double clicking on C:\Program Files (x86)\Unitron TrueFit\TrueFit.exe
- Next click on the menu item Help > Support > Register with Noah; Unitron TrueFit should now be registered correctly.
Remote Adjust
Yes, previous adjustments, including the initial fitting can be selected in the Remote Plus app by navigating to Settings > My hearing aids > Hearing aid adjustments. Simply select the preferred adjustment and tap 'Apply Adjustment'.
If the AAM isn’t 100% in the session that you opened, you will receive a warning when you go to modify the gain offset for your client. This is the same warning that you receive during a standard TrueFit session when AAM is less than 100%.
You have the ability to go up or down by 15 steps with each offset. Each step that you go is approximately equal to 1db. This means that the max gain change that can be applied in a remote adjustment is +/- 15 db. We recommend that if you need to make changes greater than 8db, you should bring your client in for an appointment and a full fitting review.
Error messages
Ensure that the Bluetooth® icon in the computer system toolbar is blue
- If the icon is red and you are using an external Bluetooth device, ensure it is plugged in.
- If the icon is red and you are using an internal Bluetooth device, ensure it is turned on.
- Check your computer owner's manual regarding enabling the Bluetooth device.
Ensure NOAHlink is powered on and the battery is charged
Ensure NOAHlink is positioned with ~10 meters of the programming computer
Run the NOAHlink properties program which can be found in the Options > Preferences > Fitting Device > NOAHlink menu. Using the NOAHlink Properties tool, Search and then Connect to the NOAHlink.
If the NOAHlink Properties tool does not locate and connect to the NOAHlink device, contact Unitron for support.
- Make sure NOAHlink Wireless is firmly plugged into a USB port of the computer
- Make sure the hearing instruments you are fitting are Bluetooth enabled
- Go to Options > Preferences > Fitting Device > NOAHlink Wireless and press the Check Connection button. If connection is not found, this could mean the driver is not properly installed. Install the driver here
- Try the troubleshooting guidelines for NOAHlink Wireless from HIMSA
If you have tried all of the above and are still unable to fix the problem, please contact Unitron for support.
- Unplug the HI-PRO power cable and plug it back in again firmly. Ensure the HI-PRO power light is on
- Check the serial or USB cable and ensure it is firmly plugged into the computer system and the HI-PRO
- Run a HI-PRO check which can be found in the Options > Preferences > Fitting Device > HI-PRO menu. Confirm the HI-PRO connection method reflects your current setup using the HI-PRO configuration button.
- If you have tried all of the above and are still unable to fix the problem, please contact Unitron for support.
